Model
|
CA400
|
CA600
|
CA800
|
CA1000
|
CA1200
|
|
20Hz-20KHz,0.1% THD+N
|
|
|
8ΩStereo Power
|
400Wx2
|
600Wx2
|
800Wx2
|
1000Wx2
|
1200Wx2
|
|
4ΩStereo Power
|
600Wx2
|
900Wx2
|
1200Wx2
|
1500Wx2
|
1800Wx2
|
|
8ΩBridge Mono Power
|
1200W
|
1800W
|
2400W
|
3000W
|
3600W
|
|
Frequency Response (+/-0.3dB,1W/8Ω)
|
20Hz-20KHz,-3dB@100KHz
|
|
Protection
|
Soft Start, Short-circuit, thermal,
ultrasonic, Infrasonic DC fault, over current, ACL.
|
|
THD+N
|
<0.03%
|
<0.03%
|
<0.05%
|
<0.05%
|
<0.05%
|
|
Damping Factor
|
300:1
|
400:1
|
450:1
|
500:1
|
600:1
|
|
Input Sensitivity(Rated Power at 8Ω)
|
0.775V, 1.0V, 1.4V
|
|
Input Impedance (Balance/Unbalance)
|
20KΩ/Balance, 10KΩ/Unbalance
|
|
S/N Ratio
|
>95dB
|
|
Segregation ratio
|
>70dB
|
|
Slew Ratio
|
30V/μS
|
|
Input Connectors(per channel)
|
3-pin XLR
|
|
Output Connectors(per channel)
|
Neutrik® NL4 Speakon®
|
|
Power Supply(Factory Configured)
|
220V-240V,50-60Hz
|
|
Cooling
|
variable speed fans
|
|
Led Indicators
|
Protect, Clip, Signal, Power
|
|
Packing Dimensions
|
585x580x160
|
660x590x230
|
|
Height
|
2U
|
3U
|
|
Weight
|
25.0kgs
|
28.0kgs
|
36.0kgs
|
42.0kgs
|
45kgs
|
|
Warranty
|
12months
|
|
|
